OLIDE - Autodoor Motion & Door Radar Sensor For Access
Control System - Detect Sensor.
Model: Motion Sensor |
One Year Warranty
Price: Qr.450/- [Qty: 10 InStock]
Suitable for:
Standalone
All Automations
indoor
Product Details: Microwave sensor is also called automatic door radar, is popular used in the automatic door systems, for detect the pedestrian's movement. It gives signal to the control board for opening the door.
Product specifications:
- => Technology: Microwave and Microprocessor
- => Principle: Doppler shift phenomenon
- => Transmitting frequency: 24.125 Ghz
- => Frequency density: ≤5mW/cm2
- => Mounting height: 4m Max
- => Radiation angle:
-> horizontal: 120°
-> vertical: 80°
- => Detection area(standard data): 4m(width)x3m(deep)
- => Detection mode: motion
- => Minimum detection speed: 5cm/s (test along the antennae coordinates)
- => Detection zone adjustment: Adjust the antenna angle.
- => Sensitivity adjustment: Adjust the potentiometer
- => Operating Temprature: -10°C - 55°C
- => Anti-Interference: EMC comply with the 89/336EEC standard
- => Power supply: 12-24V AC/DC
- => Power supply frequency: 50 - 60Hz
- => Power consumption: ≤2W
- => Output: Standard relay output
- => Maximum contacts voltage: AC 220V, DC 28V.
- => Maximum contacts current: 1A
- => Output hold time: 1Sec
 |
